Fluke 718EX 30 Intrinsically Safe Pressure Calibrator, -12 to 30 psi
Fluke 718EX 30 Intrinsically Safe Pressure Calibrator, -12 to 30 psi
| Brand: | Fluke |
| Product Code: | 718EX 30 |
| Availability: | In Stock |
-
$3,943.55
- $4,809.21
Fluke 718Ex 30 Intrinsically Safe Pressure Calibrator, -12 to 30 psi - 718EX-30
Description
The Fluke 718Ex 30 is an Intrinsically Safe, compact pressure calibrator designed for high-precision tasks in explosive environments. Certified to ATEX and CSA standards, this rugged tool allows technicians to safely perform pressure calibration on transmitters, gauges, and switches within hazardous zones. With its integrated pressure/vacuum hand pump, the 718Ex 30 provides a fully self-contained solution for low-pressure applications up to 30 psi (2 bar).
Engineered for the most demanding field conditions, the 718Ex 30 offers an exceptional accuracy of 0.025% of full scale. The unique pump design is not only easy to use but also field-serviceable; clean-out ports allow for quick maintenance if the internal pump is exposed to fluids. Its lightweight and durable construction, protected by a specialized Ex-rated holster, ensures reliability in refineries, chemical plants, and offshore platforms.
Technical Specifications
| Safety Certification | ATEX II 1G Ex ia IIC T4 compliant |
| Pressure Range | -12 psi to 30 psi (-850 mbar to 2 bar) |
| Pressure Resolution | 0.001 psi / 0.1 mbar |
| Pressure Accuracy | 0.025% of Full Scale |
| mA Measurement | 0 mA to 24 mA (0.02% Accuracy) |
| mA Resolution | 0.001 mA |
| Loop Power | Not available (Intrinsically Safe limitation) |
| Media Compatibility | Non-corrosive Gases only |
| Pressure Connection | 1/8" NPT Female |
| Operating Temperature | -10°C to 50°C |
| Weight | 2.1 lbs / 0.95 kg |
| Warranty | Three Years (Manufacturer) |
Features
- Intrinsically Safe: Approved for use in Zone 1 and Zone 2 hazardous areas.
- Integrated Hand Pump: Manual pressure and vacuum generation with a precision vernier for fine adjustments.
- Dual Reading Display: Simultaneously view pressure and current (mA) for streamlined troubleshooting.
- Easy Maintenance: Pump clean-out ports allow users to clear the pump of contaminants in the field.
- Min/Max/Hold: Essential functions for capturing and analyzing pressure peaks and stable readings.
- Ex-Rated Holster: High-impact protective red holster designed specifically for safety-critical environments.
- Ready for Compliance: Ships with a NIST-traceable certificate of calibration.
Included in Package
- Fluke 718Ex 30 Pressure Calibrator
- Protective Red Holster (Ex-Designated)
- TL75 Test Leads & AC175 Alligator Clips
- NIST-Traceable Calibration Certificate
- One (1) 9V Alkaline Battery
- User Manual & Safety Documentation
