The Suzuki DF2.5S4 2.5HP Outboard Motor is a compact and lightweight 4-stroke marine engine designed for small boats, dinghies, and tenders. It offers easy portability, smooth operation, excellent fuel efficiency, and reliable power for recreational boating and auxiliary use.

Specifications:

• Engine Type: 4-Stroke OHV, 1-Cylinder / 2 Valves
• Displacement: 68 cc (4.15 cu.in.)
• Bore & Stroke: 48 x 38 mm (1.89" x 1.50")
• Full Throttle RPM Range: 5,250 - 5,750 RPM
• Alternator Output: None (N/A)
• Dry Weight Range: 29 lbs (13.5 kg)
• Rated Power: 2.5 HP
• Fuel Delivery: Carburetor
• Steering Type: Tiller Handle (360° rotation)
• Shaft Length: 15" (Short Shaft)
• Starting System: Manual Recoil
• Cooling System: Water cooled
• Ignition System: Suzuki PEI Pointless Electronic Ignition
• Exhaust: Above propeller
• Lubrication System: Wet sump
• Oil Capacity: 0.3 L (0.32 US quart)
• Trim Range: 4-Position manual pin adjustment
• Shallow Water Drive: 2-Position settings
• Gear Ratio: 2.15:1
• Gear Shift: F-N (Forward-Neutral, uses 360° steering for reverse)
• Standard Propeller Type (Diameter x Pitch): 3-Blade aluminum, 7.5" x 5.5"
• Oil Pressure Alert: Visual indicator window
• Temperature Alert: N/A
• Rev Limiter: Standard
• Fuel Tank Capacity: 0.26 gal (1.0 Liter) built-in internal tank
