The Lowrance Elite FS 10 Dual Boat in a Box is a complete marine fishfinder and chartplotter system featuring two 10-inch Elite FS multifunction displays, an Active Imaging 3-in-1 transducer, and a POINT-1 GPS antenna.

The Elite FS 10 combines CHIRP sonar with SideScan and DownScan Imaging, while FishReveal helps identify fish against detailed underwater structure. The system also includes preloaded C-MAP Discover OnBoard charts and supports C-MAP Genesis Live mapping.

This package is designed as a connected boat electronics system, with NMEA 2000 and Ethernet connectivity, wireless networking, and compatibility with additional Lowrance technologies including ActiveTarget 2 Live Sonar and Active Imaging HD with the appropriate additional hardware.

Features:

• ActiveTarget 2 Live Sonar ready
• Active Imaging 3-in-1 ready
• Active Imaging HD 3-in-1 ready with a S3100 Sonar Module
• FishReveal
• Preloaded C-MAP Discover Onboard with 1' contours 19,000 lakes across the U.S. and more than 9,400 in Canada, plus mapping options including C-MAP, Navionics and more

C-MAP Easy Routing, Navionics Autorouting Capability:

• C-MAP Genesis Live onscreen mapping
• High-resolution multi-touch touchscreen
• Integrated wireless, NMEA 2000 and Ethernet connectivity
• Full touchscreen control of Recon and Ghost Trolling Motor, as well as Power Pole Anchors
• Sirus XM weather compatibility with WM4

Target Fish Live with ActiveTarget 2 Live Sonar:

Fish smarter when you know exactly what fish are doing – in real time – with ActiveTarget 2 Live Sonar. Enjoy high-resolution views of fish movements, tracking them as they swim in and around cover. Watch their real-time response to your lure and you will know if your current technique is working or if it's time to switch things up. Note: No splitscreen options in 10 & 12 Models.

Find More Fish with Proven Lowrance Sonar:

See structure and cover with Active Imaging and Active Imaging HD 3-in-1 sonar featuring CHIRP, SideScan and DownScan Imaging with FishReveal. Get the best of CHIRP sonar and DownScan Imaging on one screen with FishReveal, a Lowrance exclusive that helps you easily recognize fish from structure and cover on high-detailed DownScan images.

Find Key Fishing Areas with C-MAP Discover Onboard:

Enjoy the high-resolution detail of C-MAP Discover Onboard inland and coastal charts built into Elite FS displays. From finding key fishing areas, like ledges, drop-offs and ditches to navigating with precision to fish-holding areas, you will have more success on the water with high-resolution 1' contours on 19,000 lakes across the U.S. and more than 9,400 in Canada. Active Imaging HD requires S3100 Module.

10" Display Specifications:

• Resolution: 1280 x 800
• Viewing Angle: 85 deg. top/bottom, 85 deg. left/right
• Brightness: > 1200 nits
• Touch screen: Multi-touch
• Weight: 3.66 lbs (1.66 kg)
• Compass Safe Distance: 2.1' (65 cm)

Environmental Specifications:

• Operating Temperature Range: -15°C to +55°C (5°F to 131°F)
• Waterproof Rating: IPX6, IPX7

Electrical Specifications:

• Supply Voltage: 12V DC (10 - 17V DC min - max)
• Recommended Fuse Rating: 3A
• Power Consumption Maximum: 34.5W (2.5 at 13.8V DC)

Interface/Connectivity Specifications:

• NMEA 2000: 1 port (Micro-C connector)
• Data Card Reader: 1x slot (microSD, SDXC)
• Ethernet: 1 port, (5-pin Ethernet connector, 100Base-T)
• Sonar: 1 port (9-pin connector)
• Wi-Fi Internal: 802.11b/g/n : No wireless networking between units
• Bluetooth: 4.0 with support for Bluetooth Classic
• GPS: 10 Hz high speed update WAAS, MSAS, EGNOS, GLONASS

Included:

• Elite FS with Active Imaging 3-in-1 Transducer
• Elite FS - No Transducer
• POINT-1 GPS Antenna
• Ethernet cable - 7.6 m (25')
• N2K start kit
• N2K T-joiner
